Size
|
75"
|
|
Panel Brand
|
BOE,LG,AUO
|
|
Screen Assembly Process
|
Frame/Zero Bonding Technology
|
|
Type
|
TFT-LCD S-PVA
|
|
Resolution
|
3840 × 2160 (UHD) @60hz, 4K UHD screen
|
|
Brightness
|
350 cd/m² (brightness can be customized)
|
|
Contrast Ratio
|
1200:1
|
|
Visual Angle (horizontal/vertical)
|
178°/178°
|
|
Response time
|
8ms
|
|
Visual area(mm)
|
1652.8*930.2mm
|
|
Color gamut (NTSC)
|
72%
|
|
Backlight
|
straight down DLED
|
|
Display scale
|
16:9
|
|
Life time
|
≧50,000 hrs
|
|
|
|
Model
|
T982
|
|
System version
|
Android 11.0
|
|
CPU
|
Quad-core ARM Cortex-A55
|
|
GPU
|
Mali-52
|
|
Chip brand
|
Amlogic
|
|
Storage
|
4G+128G/8G+128G(Optional)
|
|
Input Ports
|
Touch USB,RJ45,AV IN,HDMI 1,HDMI 2,RS232,Android USB 2.0,Android USB 3.0
|
|
Output Ports
|
AV OUT,Earphone,SPDIF OUT
|
|
Video
|
MPEG-1/2/4,AVS2 MP,H.264,H265,VP9
|
Infrared touch characteristic
|
|
Touch Points
|
20 Points
|
|
Glass Type
|
4mm Tempered Glass
|
|
Glass transmittance
|
> 88% (higher transmittance depends on glass surface treatment technology such as AR/AG)
|
|
Positional resolution
|
4096X4096
|
|
Positional accuracy
|
More than 90% of the touch area is 2mm
|
|
The interface definition
|
USB 2.0(Full speed)
|
|
Touch the strength
|
Zero pressure touch
|
|
The light resistance
|
YES
|
|
Induction life
|
6 million times
|
|
Response time
|
<8ms
|
|
Power supply mode
|
Full duplex usb-powered DC +5V up to 500mA
|
|
|
|
Power consumption (typical value)
|
200W
|
|
Input voltage
|
AC110-240V~(+/-10%),50/60Hz,
|
|
Standby power consumption
|
≤0.5W
|
|
Switching power supply
|
European standard 220V two - phase three - wire system
|
Mechanical Specification Parameters
|
|
N.W.(kg)
|
47.2 Kg
|
|
G.W.(kg)
|
53.5Kg
|
|
Product size(W x H x D)
|
1722.1*1000.6*92.8mm
|
|
Package size(W x H x D )
|
1780*1067*200.5mm
|
|
Shell material (face frame/back shell)
|
Plastic/Sheet metal
|
|
Shell color (face frame/back shell)
|
Black/Gray
|
|
Installation Methods
|
Wall-mounted, Mobile bracket
|
|
Cooking Way
|
Temperature-controlled fan dissipates heat
|
|
|
|
Working temperature
|
-10℃~55℃
|
|
Working humidity
|
10%~90%(No condensation)
|
|
Storage temperature
|
-20℃~60℃
|
|
Storage humidity
|
10%~90%(No condensation)
|
|
Display mode
|
S-ips, often black display, transmission
|
|
Maximum service time (hours/day)
|
24 hours
|
|
|
|
Audio Output Power
|
2x15Ω/8W(built in)
|
|
Support for input mode
|
Finger/Pen
|
|
|
|
User manual
|
Manual, warranty card, certificate of conformity
|
|
Cable
|
The power cord
|
|
Others(optional accessories)
|
Remote control, Wall mount,Mobile bracket,HDMI cable,USB touch cable,Markers,Magnetic stylus,Camera&Microphone
|
